Eaton Fuse HRC Offset Bolted Tags Bs88 10A
£3.58 Incl. VAT
This is an Industrial Fuse Link, with offset bolted tags. The range of British standard Low Voltage Fuse Link size is A2, for protection of general industrial applications. · · · Good peak let-through current limitation · · 1: 1.6 Selective coordinate ratio between ‘minor’ and ‘major’ fuse · · Power loss values well within the limits of IEC 60269 · · Recyclable
Out of Stock
Description
Technical Specifications Technical Specifications HRC fuse Colour code None Type of fuse status indicator None Fuse system according to IEC 60269 Fuse system E Utilization category gG (cable protection/equipment protection) Fuse construction type according to IEC 60269 A2 Mounting holes M5 Current type AC Rated current 10 A Breaking capacity 80 kA Rated voltage AC 550 V Centre-to-centre distance of connections 73 mm Power loss at rated current 2.1 W
