Eaton Fuse HRC Offset Bolted Tags Bs88 20A
Eaton Fuse HRC Offset Bolted Tags Bs88 20A
Eaton Fuse HRC Offset Bolted Tags Bs88 20A - Image 2

Eaton Fuse HRC Offset Bolted Tags Bs88 20A

£3.84 Incl. VAT

AAO20 is an Industrial Fuse Link, with offset bolted tags. The range of British standard Low Voltage Fuse Link size is A2, for protection of general industrial applications. · · · Breaking Capacity: 80kA @ 500V AC · · Current Rating: 20A · · Length: 85mm · · Voltage Rating: 550V AC · · Fixing Centre: 73mm · · Good peak let-through current limitation · · 1: 1.6 Selective coordinate ratio between ‘minor’ and ‘major’ fuse · · Power loss values well within the limits of IEC 60269

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: AAO20 Categories: , Brand: Product Code: 2500012738

Description

Technical Specifications  Technical Specifications HRC fuse Colour code None Fuse system according to IEC 60269 Fuse system E Type of fuse status indicator None Utilization category gG (cable protection/equipment protection) Fuse construction type according to IEC 60269 A2 Mounting holes M5 Current type AC Rated voltage AC 550 V Breaking capacity 80 kA Power loss at rated current 1.9 W Centre-to-centre distance of connections 73 mm Rated current 20 A
