Eaton MCB DP Type D 20A 10/15Ka
£57.97 Incl. VAT
EM miniature circuit-breaker, 2 pole, trip type: D, rated operational current In: 20 A, rated switching capacity according to IEC/EN 60947-2: 15 kA, rated switching capacity according to IEC/EN 60898-1: 10 kA, switchgear for residential and non-residential applications · · · High-quality miniature circuit breakers for commercial and residential applications · · Comprehensive range of accessories suitable for subsequent installation · · 3-position DIN rail clip, permits removal from existing busbar system · · Rated breaking capacity 10 kA according to IEC/EN 60898-1 · · Tripping characteristics B, C and D · · Rated currents up to 63 A
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) D Voltage type AC Rated current 20 A Rated insulation voltage Ui 440 V Rated voltage 230 V Over voltage category 3 Pollution degree 2 Current limiting class 3 Recess depth 70.5 mm Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 15 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 15 kA Rated impulse-withstand voltage (Uimp) 4 kV Number of poles (total) 2 Number of protected poles 2 Width in number of modular spacings 2 Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Additional equipment possible Yes Explosion-proof No Concurrently switching N-neutral No Flush-mounted installation No
