Eaton MCB SP Type C 32A 25Ka
£81.00 Incl. VAT
EM miniature circuit-breaker, 1 pole, trip type: C, rated operational current In: 32 A, rated switching capacity according to IEC/EN 60947-2: 25 kA, switchgear for residential and non-residential applications · · · Complete and configurable enclosures MCBs, MCCBs, ACBs
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) C Degree of protection (IP rating) IP20 Voltage type AC Rated voltage 230 V Over voltage category 3 Width in number of modular spacings 1.5 Pollution degree 2 Rated insulation voltage Ui 440 V Current limiting class 3 Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity Icn EN 60898 at 400 V 0 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 0 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 25 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 25 kA Number of poles (total) 1 Number of protected poles 1 Rated current 32 A Recess depth 75 mm Frequency 50 – 60 Hz Connectable conductor cross section solid-core 2.5 – 50 mm² Connectable conductor cross section multi-wired 2.5 – 50 mm² Ambient temperature during operating -25 – 55 °C Explosion-proof No Additional equipment possible Yes Concurrently switching N-neutral No Flush-mounted installation No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
