Eaton MCCB Triple Pole Incoming NZM2 Frame 250A 36kA
£763.75 Incl. VAT
Eaton Memshield 3 Incoming Moulded Case Circuit Breaker is certified to IEC60947-2 standards. The MCCB panel board providing all the options you need from a straight forward panel board to a comprehensive panel board system. The range now offers a variety · · · Providing safety, reliability and performance in commercial, industrial applications · · Maximum cable capacity 185mm² · · Adjustable trip · · Thermal trip adjustment 0.8 to 1 x In, magnetic trip adjustment 6 to 10 x In
4 available – delivery in 1–2 days
Description
Technical Specifications Technical Specifications Moulded case circuit breaker (MCCB) Position of connection for main current circuit Front Degree of protection (IP rating) IP20 Type of control element Rocker lever Device construction Built-in device fixed built-in technique Number of auxiliary contacts as normally open contact 0 Number of poles 3 Overload release current setting 200 – 250 A Adjustment range short-term delayed short-circuit release 0 – 0 A Rated voltage 690 – 690 V Rated permanent current Iu 250 A Number of auxiliary contacts as normally closed contact 0 Number of auxiliary contacts as change-over contact 0 Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 36 kA Power loss 58.1 W Adjustment range undelayed short-circuit release 0 – 0 A Motor drive integrated No Switched-off indicator available No Suitable for DIN rail (top hat rail) mounting No Motor drive optional Yes DIN rail (top hat rail) mounting optional Yes Complete device with protection unit Yes With integrated under voltage release No Integrated earth fault protection No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
