Eaton Memshield 3 MCB SP Type B 10A 10/15kA
Eaton Memshield 3 MCB SP Type B 10A 10/15kA
Eaton Memshield 3 MCB SP Type B 10A 10/15kA - Image 2
Eaton Memshield 3 MCB SP Type B 10A 10/15kA - Image 3
Eaton Memshield 3 MCB SP Type B 10A 10/15kA - Image 4

Eaton Memshield 3 MCB SP Type B 10A 10/15kA

£22.15 Incl. VAT

· · DIN rail mountable and suitable for use with both pin and comb type busbar systems · · Suitable for 230/400 VAC systems and are calibrated for use at 40°C · · The Eaton MCB are fitted with box clamp terminals suitable for use with cables up to 25mm2, and have a unique box clamp barrier to prevent incorrect cable insertion · · These devices suite with the other modular devices including RCBOs, RCCBs and isolators, for use within Eaton Memshield 3 Distribution boards and a wide range of other applications · · Positive contact is flag indicator · · Operating temperature -25 to 55 °C · · Impulse withstand voltage 5kV · · Energy limiting class is 3

156 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EMBH110 Categories: , , Brand: Part Number: 2500330647

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) B Voltage type AC Rated current 10 A Recess depth 70.5 mm Rated voltage 240 V Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Rated impulse-withstand voltage (Uimp) 4 kV Rated insulation voltage Ui 440 V Current limiting class 3 Pollution degree 2 Over voltage category 3 Width in number of modular spacings 1 Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 0 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 0 kA Number of poles (total) 1 Number of protected poles 1 Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 55 °C Flush-mounted installation Yes Additional equipment possible Yes Concurrently switching N-neutral No Explosion-proof No · Technical Data Sheet – Click to Download
