Eaton Memshield 3 RCBO 1P+N 32A Type C10kA 30MA EMCH140R30C - 17.7 x 120 x 76mm
Eaton Memshield 3 RCBO 1P+N 32A Type C10kA 30MA EMCH140R30C - 17.7 x 120 x 76mm
Eaton Memshield 3 RCBO 1P+N 32A Type C10kA 30MA EMCH140R30C - 17.7 x 120 x 76mm - Image 2
Eaton Memshield 3 RCBO 1P+N 32A Type C10kA 30MA EMCH140R30C - 17.7 x 120 x 76mm - Image 3
Eaton Memshield 3 RCBO 1P+N 32A Type C10kA 30MA EMCH140R30C - 17.7 x 120 x 76mm - Image 4

Eaton Memshield 3 RCBO 1P+N 32A Type C10kA 30MA EMCH140R30C – 17.7 x 120 x 76mm

£55.19 Incl. VAT

The Eaton Memshield-3 EMCH110R30C RCBO provides a comprehensive protection solution to a wide range of applications. Eaton RCBOs suite with the complete range of modular devices and are for use within Eaton’s MEM Memera consumer units and other applications. It provides a high degree of protection against electric shock due to direct and indirect contact. This type of RCD is required to satisfy the requirements for “additional protection” in accordance with BS7671. · · · C release characteristic · · Manufactured to IEC/EN 61009 · · DIN rail mountable in a single module width · · Accommodate cables up to 16mm² · · A 30mA RCD will trip within 40ms when a fault current of 150mA is detected

60 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EMCH140R30C Categories: , , Brand: Part Number: 2500504369

Description

Technical Specifications  Technical Specifications Earth leakage circuit breaker/RCBO Disconnection characteristic Undelayed Tripping characteristic (type/curve) C Degree of protection (IP rating) IP20 Leakage current type A Frequency 50/60 Hz Voltage type AC Rated current 40 A Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity according to EN 61009 10 kA Power loss 14.7 W Rated voltage 240 V Rated fault current 0.03 A Rated insulation voltage Ui 500 V Recess depth 69.5 mm Pollution degree 2 Surge current capacity 0.25 kA Number of protected poles 1 Current limiting class 3 Rated short-circuit breaking capacity IEC 60947-2 0 kA Number of poles (total) 1 Over voltage category 3 Rated short-circuit breaking capacity Icn according to EN 61009-1 10 kA Width in number of modular spacings 1 Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 40 °C With interlocking device No Flush-mounted installation No Anti-nuisance tripping version No Concurrently switching N-neutral No
