Eaton RCBO SP Type C 20A 100Ma 10Ka
Eaton RCBO SP Type C 20A 100Ma 10Ka
Eaton RCBO SP Type C 20A 100Ma 10Ka - Image 2

Eaton RCBO SP Type C 20A 100Ma 10Ka

£89.26 Incl. VAT

High-quality residual current device/miniature circuit breaker combination, line voltage-dependent, design width of one module unit only, specific for applications in the BS-distribution systems, permanently connected neutral conductors, contact position indicator red – green, comprehensive range of accessories suitable for subsequent installation, guide for secure terminal connection, wide range of rated fault currents, rated operational currents up to 45 A, tripping characteristics B, C, D, rated breaking capacity 10 kA · · · Electronic residual current device/miniature circuit breaker combination in only 1MU · · Design width of one module unit only · · Line voltage-independent tripping · · Contact position indicator red – green · · Can be sealed with leads in the on and off position · · Color coded switching toggle for 10kA versions (designating the rated current)

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EMCH120R100C Categories: , , Brand: Product Code: 2500504386

Description

Technical Specifications  Technical Specifications Earth leakage circuit breaker/RCBO Tripping characteristic (type/curve) C Disconnection characteristic Undelayed Frequency 50/60 Hz Degree of protection (IP rating) IP20 Leakage current type A Voltage type AC Rated short-circuit breaking capacity according to EN 61009 10 kA Power loss 6.3 W Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity Icn according to EN 61009-1 10 kA Pollution degree 2 Over voltage category 3 Number of poles (total) 1 Rated short-circuit breaking capacity IEC 60947-2 0 kA Current limiting class 3 Number of protected poles 1 Surge current capacity 0.25 kA Width in number of modular spacings 1 Rated current 20 A Rated voltage 240 V Rated insulation voltage Ui 500 V Rated fault current 0.1 A Recess depth 69.5 mm Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 40 °C Anti-nuisance tripping version No Concurrently switching N-neutral No With interlocking device No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
