Eaton RCBO SP Type C 32A 100Ma
£89.26 Incl. VAT
Electronic residual current operated circuit-breaker with overcurrent protection; 32A; 100mA; miniature circuit-breaker characteristic curve: C; 1p; residual current circuit-breaker trip characteristic: A · · · Electronic residual current device/miniature circuit breaker combination in only 1MU · · Design width of one module unit only · · Line voltage-independent tripping · · Contact position indicator red – green · · Can be sealed with leads in the on and off position · · Color coded switching toggle for 10kA versions (designating the rated current)
Description
Technical Specifications Technical Specifications Earth leakage circuit breaker/RCBO Tripping characteristic (type/curve) C Disconnection characteristic Undelayed Degree of protection (IP rating) IP20 Frequency 50/60 Hz Voltage type AC Leakage current type A Rated current 32 A Recess depth 69.5 mm Rated short-circuit breaking capacity according to EN 61009 10 kA Rated voltage 240 V Power loss 10.7 W Rated short-circuit breaking capacity Icn according to EN 61009-1 10 kA Over voltage category 3 Rated impulse-withstand voltage (Uimp) 4 kV Number of poles (total) 1 Pollution degree 2 Number of protected poles 1 Surge current capacity 0.25 kA Rated short-circuit breaking capacity IEC 60947-2 0 kA Width in number of modular spacings 1 Rated insulation voltage Ui 500 V Current limiting class 3 Rated fault current 0.1 A Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 40 °C Anti-nuisance tripping version No Concurrently switching N-neutral No With interlocking device No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
