Eaton RCCB Tpsn 100A 30Ma Grey
£295.82 Incl. VAT
Full range of compact residual current circuit-breaker models for a wide variety of applications, for fault and additional protection, large amount of available rated operational currents, comprehensive range of accessories, true contact position indicator, automatic reclosing possible, suitable for use outdoors (building and outdoor distribution boards) at temperatures as low as -25 °C · · · Residual Current Devices · · Contact position indicator red – green · · The 4-pole device can also be used for 2- or 3-pole connection. · · Tripping is line voltage-independent, RCD is suitable for “fault current/residual current protection · · Universal tripping signal switch suitable · · Type -A: Protects against special forms of non-smoothed residual pulsating DC
Description
Technical Specifications Technical Specifications Residual current circuit breaker (RCCB) Frequency 50 Hz Mounting method DIN rail Degree of protection (IP rating) IP20 Voltage type AC Leakage current type AC Rated current 100 A Number of poles 4 Rated voltage 400 V Rated insulation voltage Ui 440 V Surge current capacity 0.25 kA Pollution degree 2 Rated fault current 0.03 A Short-circuit breaking capacity (Icw) 10 kA Recess depth 70.5 mm RAL-number (similar) 7035 Rated impulse-withstand voltage (Uimp) 4 kV Width in number of modular spacings 4 Connectable conductor cross section solid-core 1.5 – 35 mm² Connectable conductor cross section multi-wired 1.5 – 16 mm² Ambient temperature during operating -25 – 60 °C Selective protection No Additional equipment possible Yes Short-time delayed tripping No With interlocking device Yes Explosion-proof No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
