Eaton Switch Emergency Stop Surface 3Ph 6P IP65 32A 380-400V 50/60Hz
Eaton Switch Emergency Stop Surface 3Ph 6P IP65 32A 380-400V 50/60Hz
Eaton Switch Emergency Stop Surface 3Ph 6P IP65 32A 380-400V 50/60Hz - Image 2

Eaton Switch Emergency Stop Surface 3Ph 6P IP65 32A 380-400V 50/60Hz

£126.83 Incl. VAT

Main switch, Product range: Main switch, maintenance switch, Repair switch, Part group reference: T3, Stop Function: Emergency switching off function, With red rotary handle and yellow locking ring, 6 pole, Locking facility: Lockable in the 0 (Off) position, Degree of Protection: IP65, Design: surface mounting, Switching angle: 90 °, Motor rating AC-23A, 50 – 60 Hz 400 V: P = 15 kW, Rated uninterrupted current: Iu = 32 A, 4 contact unit(s), Standards: IEC/EN 60947, VDE 0660, IEC/EN 60204, Switch-disconnector according to IEC/EN 60947-3 · · · Current Rating: 32A · · Height: 180mm · · Range: xEnergy · · Width: 100mm · · Depth: 100mm · · Dimensions: 100x100x180mm

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: T3-4-15682/I2/SVB Categories: , , Brand: Product Code: 2500092542

Description

Technical Specifications  Technical Specifications Switch disconnector / isolator Device construction Complete device in housing Colour control element Red Degree of protection (NEMA) 12 Type of control element Door coupling rotary drive Type of electrical connection of main circuit Screw connection Degree of protection (IP), front side IP65 Switching power at 400 V 15 kW Rated permanent current at AC-21, 400 V 32 A Rated permanent current Iu 32 A Rated permanent current at AC-23, 400 V 32 A Number of auxiliary contacts as change-over contact 0 Conditioned rated short-circuit current Iq 1 kA Rated operation power at AC-23, 400 V 15 kW Rated short-time withstand current lcw 0.65 kA Number of switches 1 Max. rated operation voltage Ue AC 690 V Number of poles 6 Number of auxiliary contacts as normally closed contact 1 Rated operation power at AC-3, 400 V 11 kW Number of auxiliary contacts as normally open contact 1 Rated operating voltage 690 – 690 V Motor drive integrated No Version as main switch Yes Version as emergency stop installation Yes Suitable for front mounting 4-hole No Suitable for front mounting centre No Version as safety switch No Version as maintenance-/service switch Yes Interlockable Yes Version as reversing switch No Suitable for distribution board installation No Suitable for intermediate mounting No Motor drive optional No Voltage release optional No
