Prysmian FP200G3C 4.0mm² White Fire Performance Soft Skin Standard Cable 3-Core

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Protective barrier None Core colour Several Conductor category Class 2 = stranded Conductor material Copper Sheath colour White Conductor surface Bare Core identification Colour Core insulation material Polyolefin Sheath material Polyolefin Conductor Diameter 4 mm Nominal voltage U 500 V Nominal cross sectional area of conductor 4 mm² Number of cores 3 Nominal voltage U0 300 V Max. conductor temperature 70 °C Outer diameter approx. 12.3 mm Permitted cable outer temperature during assembling/handling 0 – 60 °C Oil resistant according to IEC 60811-404 No Screen Yes Drain wire Yes Low temperature resistant according to EN 60811-504+505+506 No · Technical Data Sheet – Click to Download
