Prysmian FP200G4C 1.5mm² Red Fire Performance Soft Skin Standard Cable 4-Core 500m Reel

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Protective barrier None Core colour Several Conductor material Copper Conductor category Class 1 = solid Sheath colour Red Conductor surface Bare Sheath material Polyolefin Core insulation material Polyolefin Max. conductor temperature 70 °C Core identification Colour Number of cores 4 Outer diameter approx. 10 mm Nominal voltage U0 300 V Conductor Diameter 1.5 mm Nominal voltage U 500 V Nominal cross sectional area of conductor 1.5 mm² Permitted cable outer temperature during assembling/handling 0 – 60 °C Drain wire Yes Oil resistant according to IEC 60811-404 No Low temperature resistant according to EN 60811-504+505+506 No Screen Yes · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
