FPPLUS3C 1.5mm² White Fire Performance Soft Skin Enhanced Cable 3-Core
£3,556.80 Incl. VAT
Prysmian FP PLUS is the ‘Enhanced’, hard skin, dressable fire resistant cable most commonly needed for fire alarm and emergency lighting circuits · · · Fire detection and fire alarm systems for buildings. · · Voice alarm systems and emergency voice communication. · · Emergency and escape lighting. · · Control circuits for fire safety and fire fighting systems. · · Other essential service control circuits for “Enhanced” fire resistance.
Minimum order: 500 units.
Out of stock
Description
Technical Specifications Technical Specifications Power cable < 1 kV, for fixed installations Protective barrier None Conductor material Copper Conductor surface Bare Sheath material Polyolefin Core insulation material Polyolefin Core colour Several Nominal voltage U0 300 V Number of cores 3 Outer diameter approx. 11.7 mm Nominal voltage U 500 V Nominal cross sectional area of conductor 1.5 mm² Core identification Colour Sheath colour White Conductor category Class 1 = solid Max. conductor temperature 70 °C Permitted cable outer temperature during assembling/handling 0 - 60 °C Oil resistant according to IEC 60811-404 No Low temperature resistant according to EN 60811-504+505+506 No Screen Yes Drain wire Yes · Technical Data Sheet – Click to Download
