FPPLUS4C 1.5mm² Red Fire Performance Soft Skin Enhanced Cable 4-Core
£3,111.90 Incl. VAT
Prysmian FP PLUS is the ‘Enhanced’, hard skin, dressable fire resistant cable most commonly needed for fire alarm and emergency lighting circuits · · · Fire detection and fire alarm systems for buildings. · · Voice alarm systems and emergency voice communication. · · Emergency and escape lighting. · · Control circuits for fire safety and fire fighting systems. · · Other essential service control circuits for “Enhanced” fire resistance.
Out of stock
Description
Technical Specifications Technical Specifications Power cable < 1 kV, for fixed installations Conductor category Class 1 = solid Core colour Several Conductor material Copper Protective barrier None Number of cores 4 Nominal voltage U0 300 V Nominal cross sectional area of conductor 1.5 mm² Core insulation material Polyolefin Sheath material Polyolefin Conductor surface Bare Core identification Colour Sheath colour Red Nominal voltage U 500 V Max. conductor temperature 70 °C Outer diameter approx. 12.5 mm Permitted cable outer temperature during assembling/handling 0 – 60 °C Drain wire Yes Oil resistant according to IEC 60811-404 No Low temperature resistant according to EN 60811-504+505+506 No Screen Yes · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
