Fuse HRC Offset Bolted Tags BS88 16A
Fuse HRC Offset Bolted Tags BS88 16A
Fuse HRC Offset Bolted Tags BS88 16A - Image 2
Fuse HRC Offset Bolted Tags BS88 16A - Image 3
Fuse HRC Offset Bolted Tags BS88 16A - Image 4

Fuse HRC Offset Bolted Tags BS88 16A

£2.03 Incl. VAT

Fuse, Fuse-link, low voltage, 16 A, AC 240 V, BS88, 12 x 47 mm, gL/gG, BS, offset bolted tags (slotted), street lighting cut-outs, BS88-1, Breaking Capacity 33 kA · · · Good peak let-through current limitation · · 1: 1: 6 selective coordination ratio between “minor” and “major” fuse · · Power loss values within the limits of IEC 60269 · · Pre-arching: 160 · · Total at 415V: 250 · · Watts loss: 1.5 · · Watts loss: 1.5

42 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: STD16 Categories: , , Brand: Part Number: 2500014755

Description

Technical Specifications  Technical Specifications HRC fuse Type of fuse status indicator None Colour code None Mounting holes M4 Utilization category gG (cable protection/equipment protection) Current type AC Centre-to-centre distance of connections 35 mm Rated current 16 A Rated voltage AC 240 V Breaking capacity 33 kA Power loss at rated current 1.5 W · Technical Data Sheet – Click to Download
