Fuse Link HRC Offset Bolted Tags 25A
Fuse Link HRC Offset Bolted Tags 25A
Fuse Link HRC Offset Bolted Tags 25A - Image 2

Fuse Link HRC Offset Bolted Tags 25A

£8.12 Incl. VAT

gG operating class, 660 to 690VAC/460VDC rated voltage, 73mm fixing centre · · · BS reference: A3 · · gG characteristics for cable protection · · Good peak and let-through current limitation · · 1: 1: 6 selective coordination ratio between “minor” and “major” fuse · · Power loss values well within the limits of IEC 60269 · · Compatible with Red Spot fuse holder 63A RS63 · · Pre-arching: 500 · · Total at rated voltage: 3,400 · · 73mm fixing centre · · 660-690V AC/460V DC

14 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: TIA25 Categories: , , Brand: Part Number: 2500522400

Description

Technical Specifications  Technical Specifications HRC fuse Colour code None Type of fuse status indicator None Fuse system according to IEC 60269 Fuse system E Fuse construction type according to IEC 60269 A2 Utilization category gG (cable protection/equipment protection) Current type AC/DC Rated voltage DC 460 V Mounting holes M5 Rated voltage AC 660 V Breaking capacity 80 kA Rated current 25 A Centre-to-centre distance of connections 73 mm · Technical Data Sheet – Click to Download
