Product image supplied by the manufacturer
Fusegear

Eaton Fuse Link HRC Offset Bolted Tags BS88 20A 550V AC

Brand: EatonProduct code: NIT20Go Magpie Ref: 5060062386026

NIT Red Spot industrial offset bolted tags fuse links are specifically designed for the protection of general industrial applications, e.g. power distribution, cable protection. · · · BS reference: A1 · · 1: 1: 6 selective coordination ratio between “minor” and “major” fuse · · gM characteristics for motor protection applications · · Power loss values within the limits of IEC 60269 · · Compatible with Camaster 32A compact CM32FC and Red Spot 20A RS20 · · Pre-arching: 360 · · Total at rated voltage: 2,200 · · 44mm fixing centre

£6.02inc VAT£5.02 ex VAT
In stock
UK deliveryStandard shipping is £2.99 inc VAT on eligible orders. Final delivery options are confirmed at checkout.
Quantity
1
✓ Secure checkout✓ UK customer support✓ Trusted suppliers
PRODUCT INFORMATION

Description

Technical Specifications  Technical Specifications HRC fuse Type of fuse status indicator None Fuse construction type according to IEC 60269 A1 Colour code None Utilization category gG (cable protection/equipment protection) Fuse system according to IEC 60269 Fuse system E Current type AC/DC Rated current 20 A Mounting holes M4 Rated voltage AC 550 V Centre-to-centre distance of connections 44.5 mm Breaking capacity 80 kA Rated voltage DC 250 V Power loss at rated current 1.8 W · Technical Data Sheet – Click to Download
