Hot Sale Portable Industrial Camera With Wifi Video Intercom

Description

Product description

Specification Sensor type CMOS, rolling shutter Sensor model Sony®IMX226 Pixel size 1.85 µm × 1.85 µm Sensor size 1/1.7″ Resolution 4024 × 3036 Max. frame rate 9.7 fps @4024 × 3036Mono 8/9.7 fps @4024 × 3036Bayer RG 8 Dynamic range 70.5 dB SNR 40.5dB Gain 0 dB to 20 dB Exposure time 34 μs to 2 sec Exposure mode Off/Once/Continuous exposure mode Pixel format Mono 8/10/10Packed/12/12Packed/ Bayer RG 8/10/10Packed/12/12Packed Binning Supports 1 × 1, 2 × 2, 4 × 4 Decimation Supports 1 × 1, 2 × 2, 4× 4 Reverse image Supports horizontal and vertical reverse image output Data interface Gigabit Ethernet, compatible with Fast Ethernet Digital I/O 6-pinP7connectorprovidespowerandI/O,includingopto-isolatedinput×1(Line0),opto- isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2). Power supply Typ.1.78 W@12 VDC/Typ. 1.82 W@12 VDC Lens mount C-mount Dimension 29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″) Weight Approx. 100 g (0.2 lb.) Ingress protection IP30 (under proper lens installation and wiring) Temperature Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C(-22 °F to 158 °F) Humidity 20% to 95% RH, non-condensing Client software MVS or third-party software meeting with GigE Vision Protocol Operating system 32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS Compatibility GigE Vision V2.0, GenICam Certification CE, RoHS, KC Product Description Why Choose Us
