Schneider Electric I-Line MCCB Circuit Breaker 3 Pole 40A Rating 25kA Tmd Trip Unit Adapted Compact NSX New Generation
£218.94 Incl. VAT
The Schneider Electric IL0403P25 is a 40A, 3-pole, 25kA molded case circuit breaker (MCCB). It is part of the I-Line series of MCCBs, which are designed for commercial and industrial applications. The IL0403P25 features a thermal magnetic trip unit, which provides protection against overloads and short circuits. It also has a built-in neutral-ground fault indicator, which can help to prevent electrical fires. The IL0403P25 is available in a variety of sizes and ampere ratings, and it can be used in a variety of applications, including lighting, power distribution, and motor control. · · · Number of poles 3 Pole · · Rated current 40 A at 40C · · Rated operational voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-2 · · Trip unit technology Thermal-magnetic
✓ In stock – Delivery in 1–2 days
Description
Technical Specifications Technical Specifications Moulded case circuit breaker (MCCB) Degree of protection (IP rating) IP40 Device construction Complete device in housing Number of poles 3 Type of control element Toggle Rated voltage 690 V Rated permanent current Iu 40 A · Technical Data Sheet – Click to Download
