IMO Contactor 4 Pole Open AC3 7.5Kw 18A 110V AC
IMO Contactor 4 Pole Open AC3 7.5Kw 18A 110V AC
IMO Contactor 4 Pole Open AC3 7.5Kw 18A 110V AC - Image 2

IMO Contactor 4 Pole Open AC3 7.5Kw 18A 110V AC

£77.04 Incl. VAT

IMO MC Contactor is available with 1NO contact. Features coil connection top/bottom, bifurcated auxiliary contacts and easy coil swap. It certified to CE, UL and cUL standards. · · · Coil connection top and bottom · · Bifurcated auxiliary contacts · · Easy coil swap · · International approvals (EN/IEC, UL and CSA)

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: MC18N-S-00-40110AC Categories: , , , , , Brand: Product Code: 2500835799

Description

Technical Specifications  Technical Specifications Power contactor, AC switching Voltage type for actuating AC Type of electrical connection of main circuit Screw connection Number of auxiliary contacts as normally open contact 0 Number of main contacts as normally open contact 1 Number of auxiliary contacts as normally closed contact 0 Rated operation power at AC-3, 400 V 7.5 kW Rated operation current Ie at AC-3, 400 V 18 A Number of normally closed contacts as main contact 0 Rated control supply voltage at AC 50 Hz 110 – 110 V Rated control supply voltage at AC 60 Hz 110 – 110 V Modular version No
