Inductive Barrel-Style Proximity Sensor M5 x 0.5 1.3 mm Detection PNP & NPN Output 10 30 V

The IBS04 and ICS05 series represent the optimal solution for industrial automation equipment in applications where space is limited, including toolselection, robotic position-sensing and control of micro-mechanisms. The advanced electronics is enclosed in a robust stainless steel housing. The availability of the M8-plug and 2m-PVC cable connection allow flexible mounting. On-board IO-Link communication opens up many possibilities, such as easy configuration and setup of the devices and advanced parameter setting · · · The output can be operated either as a switching output or in IO-Link mode · · Fully configurable via IO-Link v1.1. Electrical outputs can be configured as PNP/NPN/Push-pull, normally open or normally closed · · Timer functions can be set, such as switch-on and switch-off delay · · Adjustable sensing distance and hysteresis: sensing distance can be set to 33%, 50%, 75% or 100% of the maximum sensing distance · · The output can be operated either as a switching output or in IO-Link mode. · · Fully configurable via IO-Link v1.1. Electrical outputs can be configured as PNP/NPN/Push-pull, normally open or normally closed. · · Timer functions can be set, such as switch-on and switch-off delay · · Adjustable sensing distance and hysteresis: sensing distance can be set to 50% or 100% of the maximum sensing distance · · Temperature monitoring: over or under-run temperature alarms can be set
