Description

Technical Specifications  Technical Specifications Downlight / spot luminaire / floodlight Power factor 0.95 Housing material Aluminium Luminaire efficacy 88 lm/W Recess height/depth 150 mm Rated luminous flux acc. IEC 62722-2-1 2800 lm Number of poles 3 Maximum system power 32 W With light sensor No Light source included Yes Suitable for recessed mounting Yes Suitable for suspended mounting No With movement sensor No Rated ambient temperature acc. IEC62722-2-1 0 – 25 °C Colour temperature 4000 – 4000 K Nominal voltage 220 – 240 V Suitable for traverse mounting No Suitable for surface mounting No Control gear included Yes Suitable for low voltage cable system No Dimming potentiometer (integrated) No Dimming 1-10 V Yes No dimming function No Dimming manufacturer’s proprietary system No Dimming Zigbee No Dimming touch and dim No Dimming RF No Dimming LineSwitch No Suitable for clamp-mounting No Suitable for light-track mounting No Suitable for ceiling mounting Yes Suitable for pedestal/floor mounting No Dimming DMX No Dimming mains voltage modulation No Dimming DSI No Dimming with push-button No Dimming 0-10 V No Dimming programmable No Dimming sine wave reduction No Dimming DALI No · Technical Data Sheet – Click to Download
