THORNeco LED Flood light Leo IP66 300W 40000/35000/30000lm 4000K asym

Description

Technical Specifications  Technical Specifications Downlight / spot luminaire / floodlight Reflector None Lamp cap/base None Photobiological safety according to EN 62471 RG1 Colour rendering index (CRI/Ra) 80-89 Impact resistance (IK rating) IK08 Protection class according to IEC 61140 I Lumen setting adjustable Discrete positions Colour of light White Cover material Glass transparent Filament test according to IEC 60695-2-11 650 C – 30 s Control gear LED driver constant current Colour consistency (McAdam ellipse) SDCM5 Adjustability Swivelling Light distribution Asymmetric Degree of protection (IP), front side IP66 Colour temperature switchable No Light outlet Direct Voltage type AC Light source type LED non-replaceable Housing colour Anthracite Housing material Aluminium Conductor cross section – mm² Outer diameter – mm Length 523 mm Width 634 mm Number of poles – Stroboscope effect value SVM – Flickering value Pst LM – Failure rate at median useful life of 35,000 hrs at 25 °C ambient (tq) – % Unified Glare Rating (UGR) 33 Lumen maintenance at median useful life of 35,000 hrs at 25 °C ambient (tq) 85 % Failure rate at median useful life of 100,000 hrs at 25 °C ambient (tq) – % Height/depth 72 mm Maximum system power 300 W Max. number of luminaires per miniature circuit breaker C16 9 Lumen maintenance at median useful life of 50,000 hrs at 25 °C ambient (tq) 80 % Failure rate at median useful life of 50,000 hrs at 25 °C ambient (tq) – % Max. number of luminaires per miniature circuit breaker B16 8 Lumen maintenance at median useful life of 100,000 hr at 25 °C ambient (tq) – % Number of lamps 1 Rated life time L70/B50 at 25 °C 74000 h Power factor 0.91 Lamp power – W Colour temperature 4000 – 4000 K Nominal voltage 100 – 277 V Connectable conductor cross section – mm² Rated ambient temperature acc. IEC62722-2-1 -30 – 50 °C Cut-out diameter – mm With light sensor Yes With movement sensor No IFTTT support available No Control gear included Yes Luminaire with limited surface temperature, class “D“ in acc. with EN 60598-2-24 No Suitable for recessed mounting No Luminaire may be covered with thermally insulating material No Suitable for traverse mounting No Suitable for ceiling mounting No Light source included Yes Suitable for suspended mounting No Suitable for wall mounting No Fit for workplace acc. EN 12464-1 No Brushed surface No Suitable for surface mounting No Constant luminous flux control No Dimming 0-10 V No Suitable for pedestal/floor mounting No Suitable for light-track mounting No Suitable for clamp-mounting No Dimming DALI-2 No Suitable for low voltage cable system No Replaceable control gear No Dimming DSI No Dimming with push-button No Compatible with Amazon Alexa No Compatible with Google Assistant No Dimming mains voltage modulation No Dimming trailing edge No Dimming programmable No Dimming leading edge No Dimming DMX No Dimming DALI No Dimming manufacturer’s proprietary system No Dimming 1-10 V No Dimming potentiometer (integrated) No Compatible with Apple HomeKit No Dimming RF No Dimming LineSwitch No Dimming sine wave reduction No Dimming Zigbee No Dimming touch and dim No · Technical Data Sheet – Click to Download
