Legrand Line Tap Strip 2X50mm

Description

Technical Specifications  Technical Specifications Single- and multi-pole terminal strip Material insulation body Thermoplastic Colour Black Type of electrical connection 2 Screw connection Number of clamp positions per pole – Width 30.8 mm Drill hole distance centrically – mm Number of poles 1 Rated current In – A Rated voltage – V Height 59 mm Depth 30.8 mm Connectable conductor cross section fine-strand with cable end sleeve – – – mm² Connectable conductor cross section solid-core 50 – 50 mm² Connectable conductor cross section fine-strand without cable end sleeve 50 – 50 mm² Operating temperature – – – °C Connectable conductor cross section multi-wired 50 – 50 mm² Halogen free No Explosion-tested version ‘Ex e’ No Transparent No Closing plate required No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
