Legrand Transformer Control 1Phase Open Type 630Va 230-400V/115-230V

Description

Technical Specifications  Technical Specifications One-phase control transformer Type of insulation material acc. IEC 85 B Width 132 mm Height 155 mm Relative short circuit voltage 3.4 % Power consumption in standby mode – W Power – W Rated apparent power 630 VA Depth 175 mm Primary voltage 2 230 – 230 V Primary voltage 1 215 – 215 V Primary voltage 4 385 – 385 V Primary voltage 3 245 – 245 V Primary voltage 8 – – – V Primary voltage 9 – – – V Secondary voltage 4 – – – V Primary voltage 5 400 – 400 V Secondary voltage 5 – – – V Primary voltage 6 415 – 415 V Secondary voltage 6 – – – V Primary voltage 7 – – – V Secondary voltage 7 – – – V Secondary voltage 1 115 – 115 V Secondary voltage 10 – – – V Secondary voltage 2 230 – 230 V Secondary voltage 3 – – – V Primary voltage 10 – – – V Secondary voltage 8 – – – V Secondary voltage 9 – – – V Built as isolating transformer Yes Built as safety transformer No Suitable for mounting on PCB No Short-circuit-proof No Ring core No Built as energy saving transformer No Modular version No
