Lewden 40A Trip Curve C RCD Class A Residual Current 30mA 10kA RCBO
£49.78 Incl. VAT
A fully comprehensive range of 10kA RCBOs, which provides protection for cables, filament lighting circuits, heating loads and domestic applications, as well as protection against earth leakage, overload and short circuits. Lewden 10kA RCBOs are fully compatible with the TP&N range which is the complete solution to managing the distribution of electricity in commercial premises such as offices, warehouses, factories, schools, hospitals etc. · · · Designed and tested for use with Lewden branded distribution boards. · · Residual current circuit breaker with integral overcurrent protection. · · Class AC & A. · · Single module RCBOs are suitable for use in TN-S, TN-C-S, & TT network systems.
7 available – delivery in 1–2 days
Description
Technical Specifications Technical Specifications Earth leakage circuit breaker/RCBO Over voltage category – Rated short-circuit breaking capacity IEC 60947-2 – kA Rated voltage 230 V Current limiting class – Number of protected poles – Rated fault current 3 A Surge current capacity – kA Rated insulation voltage Ui – V Width in number of modular spacings 1 Pollution degree – Connectable conductor cross section solid-core – mm² Rated short-circuit breaking capacity Icn according to EN 61009-1 – kA Rated short-circuit breaking capacity according to EN 61009 10 kA Rated impulse-withstand voltage (Uimp) – kV Number of poles (total) 2 Recess depth 761 mm Rated current 40 A Connectable conductor cross section multi-wired – mm² Ambient temperature during operating – °C Anti-nuisance tripping version No Flush-mounted installation No Concurrently switching N-neutral No With interlocking device No · Technical Data Sheet – Click to Download
