LSXH 4.0mm² White Afumex Earthshield Cable 3-Core 100m Reel
LSXH 4.0mm² White Afumex Earthshield Cable 3-Core 100m Reel
LSXH 4.0mm² White Afumex Earthshield Cable 3-Core 100m Reel - Image 2
LSXH 4.0mm² White Afumex Earthshield Cable 3-Core 100m Reel - Image 3

LSXH 4.0mm² White Afumex Earthshield Cable 3-Core 100m Reel

£31.98 Incl. VAT

Prysmian LSX® is a Low Smoke, Zero Halogen (LSOH®) and flame retardant cable developed to address specific needs of the modern building services and systems · · · Low voltage circuits typically lighting and power distribution, in buildings. · · Suitable for clipped, surface, tray and void installation. · · Low smoke, zero halogen and flame retardant. · · Ideal for all non-emergency circuits in public buildings. · · Fully screened design provides EMC protection for signal clarity.

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 20175547 Categories: , , Brand: Part Number: 2500042695

Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Reaction-to-fire according to EN 13501-6: Class Aca Core colour Several Protective barrier None Conductor category Class 2 = stranded Sheath colour White Core insulation material Polyolefin Conductor material Copper Core identification Colour Sheath material Polyolefin Conductor surface Bare Nominal cross sectional area of conductor 4 mm² Outer diameter approx. 12.3 mm Permitted cable outer temperature during assembling/handling 0 – 60 °C Nominal voltage U 500 V Conductor Diameter 4 mm Nominal voltage U0 300 V Number of cores 3 Max. conductor temperature 70 °C Oil resistant according to IEC 60811-404 No Low temperature resistant according to EN 60811-504+505+506 No Screen Yes Drain wire Yes · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
