Eaton MCB SP Type C 4A 10/15Ka
Eaton MCB SP Type C 4A 10/15Ka
Eaton MCB SP Type C 4A 10/15Ka - Image 2
Eaton MCB SP Type C 4A 10/15Ka - Image 3
Eaton MCB SP Type C 4A 10/15Ka - Image 4

Eaton MCB SP Type C 4A 10/15Ka

£23.26 Incl. VAT

EM miniature circuit-breaker, 1 pole, trip type: C, rated operational current In: 4 A, rated switching capacity according to IEC/EN 60947-2: 15 kA, rated switching capacity according to IEC/EN 60898-1: 10 kA, switchgear for residential and non-residential applications · · · High-quality miniature circuit breakers for commercial and residential applications · · Comprehensive range of accessories suitable for subsequent installation · · 3-position DIN rail clip, permits removal from existing busbar system · · Rated breaking capacity 10 kA according to IEC/EN 60898-1 · · Tripping characteristics B, C and D · · Rated currents up to 63 A

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EMCH104 Categories: , , Brand: Product Code: 2500330620

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) C Degree of protection (IP rating) IP20 Voltage type AC Recess depth 70.5 mm Rated voltage 230 V Rated current 4 A Width in number of modular spacings 1 Rated insulation voltage Ui 440 V Over voltage category 3 Current limiting class 3 Pollution degree 2 Rated impulse-withstand voltage (Uimp) 4 kV Number of protected poles 1 Number of poles (total) 1 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 15 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 15 kA Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Explosion-proof No Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible Yes
