Eaton MCB Triple Pole Type C 63A 10/15kA 54 x 80 x 75mm
Eaton MCB Triple Pole Type C 63A 10/15kA 54 x 80 x 75mm
Eaton MCB Triple Pole Type C 63A 10/15kA 54 x 80 x 75mm - Image 2
Eaton MCB Triple Pole Type C 63A 10/15kA 54 x 80 x 75mm - Image 3

Eaton MCB Triple Pole Type C 63A 10/15kA 54 x 80 x 75mm

£92.36 Incl. VAT

EM miniature circuit-breaker, 3 pole, trip type: C, rated operational current In: 63 A, rated switching capacity according to IEC/EN 60947-2: 15 kA, rated switching capacity according to IEC/EN 60898-1: 10 kA, switchgear for residential and non-residential applications · · · DIN rail mountable · · Suitable for use with both pin and comb type busbar systems · · Suites RCBOs, RCCBs and isolators · · Positive contact is flag indicator · · Operating temperature: -25 to 55 °C · · Impulse withstand voltage: 4kV · · Certified by KEMA · · Designed & tested in accordance with IEC 60898 & IEC 60947-2

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EMCH363 Categories: , , Brand: Product Code: 2500331235

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) C Degree of protection (IP rating) IP20 Voltage type AC Recess depth 70.5 mm Rated voltage 240 V Rated current 63 A Current limiting class 3 Rated insulation voltage Ui 440 V Over voltage category 3 Pollution degree 2 Number of protected poles 3 Number of poles (total) 3 Width in number of modular spacings 3 Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 0 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 0 kA Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 55 °C Concurrently switching N-neutral No Additional equipment possible Yes Flush-mounted installation Yes Explosion-proof No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
