Schneider Electric Merlin Gerin Acti9 IIL Single Indicator Light Green 110-230V AC

This Acti 9 iIL is a single-phase voltage presence indicator light. The voltage is 110VAC to 230VAC or 110VDC to 130VDC. The red light on the front face lights up to indicate that a voltage is present. The connection could be done with flexible copper cables or with ferrule cables from 0.5mm² up to 2 x 2.5mm². The tightening torque for the PZ1 screwdriver to connect screw connections is 1N.m. The connection could be done with rigid copper cables from 0.5mm² minimum up to 2 x 2.5mm2 maximum. It comes with staggered terminals to simplify the connection. The LED indication light maximum consumption per indicator light is 0.3W. The Operating frequency is 50Hz or 60Hz. The service life of the LED indicator light is 100000h of constant lightning efficiency. Because of the non-interchangeability of LEDs it is a maintenance-free device. The tropicalization is Treatment 2 (relative humidity 95% at 55°C). The degree of protection is IP20. The pollution degree is 3. The width in 9mm pitches is 2. The dimensions are (W) 18mm x (H) 82mm x (D) 68mm. The weight is 65g. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 80°C. This product complies with IEC/EN 60947-5-1 standard. · · · Peace of mind that comes from using a fully modular system · · expansion and modification of an installation is not only possible but is both simple and rapid to perform · · Seamless integration with the complete range of Acti 9 products. · · Visual monitoring of electrical circuits in industrial and commercial buildings. · · Simple and rapid installation of modules in DIN rail systems · · Indicator lamps use LEDs with a service life of 100,000 hours of constant lighting · · Flashing red indicator light version available for 110V-230V AC circuits · · Front facing class II insulation provides additional protection for users when operating the device · · Compliant with IEC 60947-5-1 · · Warranty period: 18 months.
