Miniature Circuit Breaker (MCB) 10 A 3 Pole Characteristic: Type C 6kA
Miniature Circuit Breaker (MCB) 10 A 3 Pole Characteristic: Type C 6kA
Miniature Circuit Breaker (MCB) 10 A 3 Pole Characteristic: Type C 6kA - Image 2
Miniature Circuit Breaker (MCB) 10 A 3 Pole Characteristic: Type C 6kA - Image 3
Miniature Circuit Breaker (MCB) 10 A 3 Pole Characteristic: Type C 6kA - Image 4

Miniature Circuit Breaker (MCB) 10 A 3 Pole Characteristic: Type C 6kA

£85.52 Incl. VAT

This is a 10-ampere, 3-pole, C-type miniature circuit breaker (MCB). It has a 230-400V AC voltage rating and a 6kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 10-ampere rating, which means that it can safely carry a current of up to 10 amperes. It also has a 6kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 6 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 3 · · Release Characteristic C · · Amperage Rating 10A · · Voltage Type Ac · · 6 A Conventional enclosed thermal current · · Its B10D reliability data is 5 000 000. · · 5gn Vibration Resistance · · 10gn Shock Resistance / Class I Electrical Shock protection · · With interlocking, locking by solenoid (Lock on De-energisation) · · Its IP67 degree of protection makes it ideal for heavy duty use in harsh conditions.

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 239144 Categories: , , Brand: Part Number: 2500607248

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) C Voltage type AC Recess depth 70.5 mm Degree of protection (IP rating) IP20 Rated voltage 230 V Rated impulse-withstand voltage (Uimp) 4 kV Rated current 10 A Number of poles (total) 3 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Number of protected poles 3 Over voltage category 3 Current limiting class 3 Rated insulation voltage Ui 440 V Width in number of modular spacings 3 Power loss 4.5 W Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Pollution degree 2 Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Explosion-proof No Concurrently switching N-neutral No Additional equipment possible Yes Flush-mounted installation No · Technical Data Sheet – Click to Download
