Miniature Circuit Breaker (MCB) 10A 2 Pole Characteristic: Type D 10kA
Miniature Circuit Breaker (MCB) 10A 2 Pole Characteristic: Type D 10kA
Miniature Circuit Breaker (MCB) 10A 2 Pole Characteristic: Type D 10kA - Image 2
Miniature Circuit Breaker (MCB) 10A 2 Pole Characteristic: Type D 10kA - Image 3
Miniature Circuit Breaker (MCB) 10A 2 Pole Characteristic: Type D 10kA - Image 4

Miniature Circuit Breaker (MCB) 10A 2 Pole Characteristic: Type D 10kA

£57.97 Incl. VAT

This is a 10-ampere, 2-pole, D-type miniature circuit breaker (MCB). It has a 230-440V AC voltage rating and a 10kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 10-ampere rating, which means that it can safely carry a current of up to 10 amperes. It also has a 10kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 10 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 2 · · Release Characteristic D · · Amperage Rating 10A · · Voltage Type Ac · · Very compact (45mm width), DIN-rail mounting or screw fixing. · · Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).

4 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 168071 Categories: , , Brand: Part Number: 2500607267

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) D Recess depth 70.5 mm Voltage type AC Rated current 10 A Power loss 3 W Rated voltage 230 V Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Pollution degree 2 Number of protected poles 2 Rated impulse-withstand voltage (Uimp) 4 kV Over voltage category 3 Current limiting class 3 Rated insulation voltage Ui 440 V Width in number of modular spacings 2 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Number of poles (total) 2 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Concurrently switching N-neutral No Explosion-proof No Additional equipment possible Yes Flush-mounted installation No · Technical Data Sheet – Click to Download
