Miniature Circuit Breaker (MCB) 10A 3 Pole Characteristic: Type D 10 Ka
Miniature Circuit Breaker (MCB) 10A 3 Pole Characteristic: Type D 10 Ka
Miniature Circuit Breaker (MCB) 10A 3 Pole Characteristic: Type D 10 Ka - Image 2
Miniature Circuit Breaker (MCB) 10A 3 Pole Characteristic: Type D 10 Ka - Image 3
Miniature Circuit Breaker (MCB) 10A 3 Pole Characteristic: Type D 10 Ka - Image 4

Miniature Circuit Breaker (MCB) 10A 3 Pole Characteristic: Type D 10 Ka

£91.32 Incl. VAT

This is a 10-ampere, 3-pole, D-type miniature circuit breaker (MCB). It has a 230-440V AC voltage rating and a 10kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 10-ampere rating, which means that it can safely carry a current of up to 10 amperes. It also has a 10kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 10 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 3 · · Release Characteristic D · · Amperage Rating 10A · · Voltage Type Ac · · It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections.

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 168080 Categories: , , Brand: Part Number: 2500607276

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) D Voltage type AC Recess depth 70.5 mm Degree of protection (IP rating) IP20 Rated current 10 A Rated voltage 230 V Number of poles (total) 3 Number of protected poles 3 Over voltage category 3 Current limiting class 3 Width in number of modular spacings 3 Rated impulse-withstand voltage (Uimp) 4 kV Power loss 4.5 W Rated insulation voltage Ui 440 V Pollution degree 2 Connectable conductor cross section multi-wired 1 – 25 mm² Connectable conductor cross section solid-core 1 – 25 mm² Frequency 50 – 60 Hz Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Ambient temperature during operating -25 – 75 °C Explosion-proof No Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible Yes · Technical Data Sheet – Click to Download
