Miniature Circuit Breaker (MCB) 16A 1 Pole Characteristic: Type D 10 Ka
£21.73 Incl. VAT
This is a 16-ampere, 1-pole, D-type miniature circuit breaker (MCB). It has a 230-440V AC voltage rating and a 10kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 16-ampere rating, which means that it can safely carry a current of up to 16 amperes. It also has a 10kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 10 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 1 · · Release Characteristic D · · Amperage Rating 16A · · Voltage Type Ac · · Acti 9 is easy to install and environmentally friendly. Example: Its components are 100% recyclable and recoverable. · · Flexible, upgradeable solutions and simple operations · · Optimised design time, in particular for lighting solutions in buildings. · · Total coordination guaranteed by Schneider Electric. · · The electrical endurance under AC1 category is over 10exp5 switchning operations. · · The type of excitation is analog (ou analogue) with single function. The device is flashing during time delay.
Out of stock
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Voltage type AC Recess depth 70.5 mm Rated current 16 A Tripping characteristic (type/curve) D Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Current limiting class 3 Rated insulation voltage Ui 440 V Power loss 2.3 W Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated impulse-withstand voltage (Uimp) 4 kV Over voltage category 3 Connectable conductor cross section solid-core 1 – 25 mm² Frequency 50 – 60 Hz Width in number of modular spacings 1 Rated voltage 230 V Number of protected poles 1 Number of poles (total) 1 Pollution degree 2 Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Concurrently switching N-neutral No Explosion-proof No Additional equipment possible Yes Flush-mounted installation No · Technical Data Sheet – Click to Download
