Miniature Circuit Breaker (MCB) 20A 1 Pole Characteristic: Type D 10 Ka - Image 4

Miniature Circuit Breaker (MCB) 20A 1 Pole Characteristic: Type D 10 Ka

£21.73 Incl. VAT

This is a 20-ampere, 1-pole, D-type miniature circuit breaker (MCB). It has a 230-440V AC voltage rating and a 10kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 20-ampere rating, which means that it can safely carry a current of up to 20 amperes. It also has a 10kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 10 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 1 · · Release Characteristic D · · Amperage Rating 20A · · Voltage Type Ac · · Compact (45mm width), DIN-rail mounting or screw fixing. · · Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 168064 Categories: , , Brand: Part Number: 2500607260

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) D Voltage type AC Recess depth 70.5 mm Degree of protection (IP rating) IP20 Rated current 20 A Rated voltage 230 V Rated insulation voltage Ui 440 V Current limiting class 3 Pollution degree 2 Over voltage category 3 Width in number of modular spacings 1 Rated impulse-withstand voltage (Uimp) 4 kV Number of poles (total) 1 Frequency 50 – 60 Hz Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Power loss 2.2 W Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Number of protected poles 1 Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Explosion-proof No Concurrently switching N-neutral No Additional equipment possible Yes Flush-mounted installation No · Technical Data Sheet – Click to Download
