Miniature Circuit Breaker (MCB) 20A 2 Pole Characteristic: Type C 6kA
£53.63 Incl. VAT
This is a 20-ampere, 2-pole, C-type miniature circuit breaker (MCB). It has a 230-400V AC voltage rating and a 6kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a double-pole breaker, meaning that it protects one circuit at a time. It has a 20-ampere rating, which means that it can safely carry a current of up to 20 amperes. It also has a 6kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 6 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 2 · · Release Characteristic C · · Amperage Rating 20A · · Voltage Type Ac · · Compatible with Red Spot fuse holder 100A RS100 · · Pre-arching: 57,000 · · Total at 415V: 150,000 · · Watts loss: 6.5
Out of stock
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) C Voltage type AC Degree of protection (IP rating) IP20 Rated current 20 A Recess depth 70.5 mm Rated insulation voltage Ui 440 V Rated voltage 230 V Width in number of modular spacings 2 Power loss 6.9 W Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Number of poles (total) 2 Number of protected poles 2 Rated impulse-withstand voltage (Uimp) 4 kV Pollution degree 2 Current limiting class 3 Over voltage category 3 Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Explosion-proof No Additional equipment possible Yes Concurrently switching N-neutral No Flush-mounted installation No · Technical Data Sheet – Click to Download
