Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type C 6 Ka
Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type C 6 Ka
Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type C 6 Ka - Image 2
Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type C 6 Ka - Image 3
Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type C 6 Ka - Image 4

Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type C 6 Ka

£21.43 Incl. VAT

This is a 25-ampere, 1-pole, C-type miniature circuit breaker (MCB). It has a 230-400V AC voltage rating and a 6kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 25-ampere rating, which means that it can safely carry a current of up to 25 amperes. It also has a 6kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 6 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 1 · · Release Characteristic C · · Amperage Rating 25A · · Voltage Type Ac · · Handle with 4 screws fixing on door, ensuring IP65 to the mounting. · · Possible distance between back of enclosure and door 330-350mm. · · Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 239039 Categories: , , Brand: Part Number: 2500607228

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) C Recess depth 70.5 mm Voltage type AC Rated impulse-withstand voltage (Uimp) 4 kV Number of poles (total) 1 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Current limiting class 3 Over voltage category 3 Number of protected poles 1 Rated insulation voltage Ui 440 V Power loss 2.8 W Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Pollution degree 2 Width in number of modular spacings 1 Rated voltage 230 V Rated current 25 A Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Additional equipment possible Yes Flush-mounted installation No Explosion-proof No Concurrently switching N-neutral No · Technical Data Sheet – Click to Download
