Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type D 10 Ka
Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type D 10 Ka
Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type D 10 Ka - Image 2
Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type D 10 Ka - Image 3
Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type D 10 Ka - Image 4

Miniature Circuit Breaker (MCB) 25A 1 Pole Characteristic: Type D 10 Ka

£21.73 Incl. VAT

This is a 25-ampere, 1-pole, D-type miniature circuit breaker (MCB). It has a 230-440V AC voltage rating and a 10kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 25-ampere rating, which means that it can safely carry a current of up to 25 amperes. It also has a 10kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 10 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 1 · · Release Characteristic D · · Amperage Rating 25A · · Voltage Type Ac · · Includes 1NO and 1NC auxiliary · · Mechanical durability: 15 Mcycles · · Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). · · Tightening torque: 1.7Nm · · Ambient operating temperature: -5°C to 60°C · · IP20 Degree of protection (front face)

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 168065 Categories: , , Brand: Part Number: 2500607261

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) D Voltage type AC Degree of protection (IP rating) IP20 Recess depth 70.5 mm Rated current 25 A Rated insulation voltage Ui 440 V Number of protected poles 1 Number of poles (total) 1 Rated impulse-withstand voltage (Uimp) 4 kV Pollution degree 2 Over voltage category 3 Width in number of modular spacings 1 Rated voltage 230 V Current limiting class 3 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Connectable conductor cross section multi-wired 1 – 25 mm² Connectable conductor cross section solid-core 1 – 25 mm² Frequency 50 – 60 Hz Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Power loss 2.5 W Ambient temperature during operating -25 – 75 °C Additional equipment possible Yes Explosion-proof No Concurrently switching N-neutral No Flush-mounted installation No · Technical Data Sheet – Click to Download
