Miniature Circuit Breaker (MCB) 2A 3 Pole Characteristic: Type C 6kA
Miniature Circuit Breaker (MCB) 2A 3 Pole Characteristic: Type C 6kA
Miniature Circuit Breaker (MCB) 2A 3 Pole Characteristic: Type C 6kA - Image 2
Miniature Circuit Breaker (MCB) 2A 3 Pole Characteristic: Type C 6kA - Image 3
Miniature Circuit Breaker (MCB) 2A 3 Pole Characteristic: Type C 6kA - Image 4

Miniature Circuit Breaker (MCB) 2A 3 Pole Characteristic: Type C 6kA

£115.98 Incl. VAT

This is a 2-ampere, 3-pole, C-type miniature circuit breaker (MCB). It has a 230-400V AC voltage rating and a 6kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a triple-pole breaker, meaning that it protects one circuit at a time. It has a 2-ampere rating, which means that it can safely carry a current of up to 2 amperes. It also has a 6kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 6 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 3 · · Release Characteristic C · · Amperage Rating 2A · · Voltage Type Ac · · Positive opening · · Ambient air temperature for operation -25…70 °C

5 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 239122 Categories: , , Brand: Part Number: 2500607245

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) C Voltage type AC Degree of protection (IP rating) IP20 Recess depth 70.5 mm Rated current 2 A Rated insulation voltage Ui 440 V Rated voltage 230 V Width in number of modular spacings 3 Over voltage category 3 Number of protected poles 3 Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Power loss 4.2 W Number of poles (total) 3 Rated impulse-withstand voltage (Uimp) 4 kV Pollution degree 2 Current limiting class 3 Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Concurrently switching N-neutral No Explosion-proof No Additional equipment possible Yes Flush-mounted installation No · Technical Data Sheet – Click to Download
