Miniature Circuit Breaker (MCB) 40A 1 Pole Characteristic: Type C 6 Ka
£21.73 Incl. VAT
This is a 40-ampere, 1-pole, C-type miniature circuit breaker (MCB). It has a 230-400V AC voltage rating and a 6kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 40-ampere rating, which means that it can safely carry a current of up to 40 amperes. It also has a 6kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 6 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 1 · · Release Characteristic C · · Amperage Rating 40A · · Voltage Type Ac · · Fully shrouded Neutral busbar for increased safety · · Choice of metering option to suit application needs and aid compliance with latest Building Regulati · · Door opens 180 to provide easy access and device operation · · Standard incomer Switch Disconnector rating of 125A provides higher rated solution for commercial bu · · 125A · · 4 Ways
Out of stock
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) C Voltage type AC Rated voltage 230 V Rated current 40 A Recess depth 70.5 mm Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated impulse-withstand voltage (Uimp) 4 kV Width in number of modular spacings 1 Rated insulation voltage Ui 440 V Pollution degree 2 Over voltage category 3 Current limiting class 3 Power loss 3.4 W Connectable conductor cross section multi-wired 1 – 25 mm² Connectable conductor cross section solid-core 1 – 25 mm² Frequency 50 – 60 Hz Number of protected poles 1 Number of poles (total) 1 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Ambient temperature during operating -25 – 75 °C Flush-mounted installation No Concurrently switching N-neutral No Explosion-proof No Additional equipment possible Yes · Technical Data Sheet – Click to Download
