Miniature Circuit Breaker (MCB) 40A 2 Pole Characteristic: Type C 6kA
Miniature Circuit Breaker (MCB) 40A 2 Pole Characteristic: Type C 6kA
Miniature Circuit Breaker (MCB) 40A 2 Pole Characteristic: Type C 6kA - Image 2
Miniature Circuit Breaker (MCB) 40A 2 Pole Characteristic: Type C 6kA - Image 3
Miniature Circuit Breaker (MCB) 40A 2 Pole Characteristic: Type C 6kA - Image 4

Miniature Circuit Breaker (MCB) 40A 2 Pole Characteristic: Type C 6kA

£56.52 Incl. VAT

This is a 40-ampere, 2-pole, C-type miniature circuit breaker (MCB). It has a 230-400V AC voltage rating and a 6kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a double-pole breaker, meaning that it protects one circuit at a time. It has a 40-ampere rating, which means that it can safely carry a current of up to 40 amperes. It also has a 6kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 6 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 2 · · Release Characteristic C · · Amperage Rating 40A · · Voltage Type Ac · · Fixing mode: Clipped on 35mm symmetrical DIN rail · · Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh). · · Tightening torque: 1.7Nm on screw terminals · · Mechanical/Electrical durability: 100000 cycles · · Ambient temperature: -20°C to 60°C · · IP20/IK04 Degree of protection

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 239107 Categories: , , Brand: Part Number: 2500607242

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) C Voltage type AC Rated voltage 230 V Rated current 40 A Rated insulation voltage Ui 440 V Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Number of poles (total) 2 Number of protected poles 2 Rated impulse-withstand voltage (Uimp) 4 kV Width in number of modular spacings 2 Over voltage category 3 Current limiting class 3 Power loss 7.5 W Recess depth 70.5 mm Connectable conductor cross section multi-wired 1 – 25 mm² Connectable conductor cross section solid-core 1 – 25 mm² Frequency 50 – 60 Hz Pollution degree 2 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Ambient temperature during operating -25 – 75 °C Explosion-proof No Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible Yes · Technical Data Sheet – Click to Download
