Miniature Circuit Breaker (MCB) 63A 1 Pole Characteristic: Type D 10 Ka
Miniature Circuit Breaker (MCB) 63A 1 Pole Characteristic: Type D 10 Ka
Miniature Circuit Breaker (MCB) 63A 1 Pole Characteristic: Type D 10 Ka - Image 2
Miniature Circuit Breaker (MCB) 63A 1 Pole Characteristic: Type D 10 Ka - Image 3

Miniature Circuit Breaker (MCB) 63A 1 Pole Characteristic: Type D 10 Ka

£27.68 Incl. VAT

This is a 63-ampere, 1-pole, D-type miniature circuit breaker (MCB). It has a 230-440V AC voltage rating and a 10kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 63-ampere rating, which means that it can safely carry a current of up to 63 amperes. It also has a 10kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 10 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 1 · · Release Characteristic D · · Amperage Rating 63A · · Voltage Type Ac · · Compact (45mm width), DIN-rail mounting or screw fixing. · · Voltage Rating: 415V · · Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). · · Frequency: 50 – 60Hz · · IP Rating: IP2X · · CE: yes

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 168069 Categories: , , Brand: Part Number: 2500607265

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) D Degree of protection (IP rating) IP20 Voltage type AC Rated current 63 A Recess depth 70.5 mm Rated insulation voltage Ui 440 V Width in number of modular spacings 1 Current limiting class 3 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated impulse-withstand voltage (Uimp) 4 kV Power loss 5.5 W Rated voltage 230 V Over voltage category 3 Pollution degree 2 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Number of poles (total) 1 Number of protected poles 1 Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Concurrently switching N-neutral No Flush-mounted installation No Explosion-proof No Additional equipment possible Yes · Technical Data Sheet – Click to Download
