Miniature Circuit Breaker (MCB) 63A 3 Pole Characteristic: Type D 10 Ka
£119.42 Incl. VAT
This is a 63-ampere, 3-pole, D-type miniature circuit breaker (MCB). It has a 230-440V AC voltage rating and a 10kA interrupting rating. Part of Eaton’s xEffect series of MCBs.This is a single-pole breaker, meaning that it protects one circuit at a time. It has a 63-ampere rating, which means that it can safely carry a current of up to 63 amperes. It also has a 10kA short-circuit rating, which means that it can safely interrupt a short-circuit current of up to 10 kA.This is a safe and reliable way to protect electrical circuits. It is a valuable tool for any electrician or facility manager. · · · Number Of Poles (Total) 3 · · Release Characteristic D · · Amperage Rating 63A · · Voltage Type Ac
Out of stock
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Voltage type AC Tripping characteristic (type/curve) D Rated current 63 A Current limiting class 3 Recess depth 70.5 mm Rated insulation voltage Ui 440 V Over voltage category 3 Pollution degree 2 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Power loss 16.6 W Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Width in number of modular spacings 3 Rated voltage 230 V Number of protected poles 3 Number of poles (total) 3 Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Concurrently switching N-neutral No Additional equipment possible Yes Flush-mounted installation No Explosion-proof No · Technical Data Sheet – Click to Download
