Module Dimmer Dual Mode c/w Trim 100W 26.5 x 55mm

Description

Technical Specifications  Technical Specifications Dimmer Depth of device 24.2 mm Height of device 57.5 mm Minimum depth of back box 25 mm Max. switching power LED 100 W Number of module spaces (modular system) 1 Width of device 25 mm Frequency 50 – 60 Hz Control voltage 220 – 240 V Core cross section 1 – 1.5 mm² Nominal power resistive load 5 – 100 W Nominal power inductive load 5 – 100 VA Nominal power capacitive load 5 – 100 VA Activated by movement sensor No Serial dimmer No Light value memory No Compatible with Apple HomeKit No Activated by RF remote control No Activated by IR remote control No Activated by presence detector No Activated by button No Dimming trailing edge No Dimming leading edge No Activated by time switch/timer No IFTTT support available No Transparent No Auxiliary input No App control No Halogen free No Compatible with Amazon Alexa No Compatible with Google Assistant No · Technical Data Sheet – Click to Download
