Newlec 16mm² M6 Copper Tube Lug
£8.14 Incl. VAT
16mm² Copper tube crimping lug M6 stud · · · Annealed to guarantee optimum ductility · · Insulation sleeve form to allow easy introduction of the conductor · · Maximum Voltage Rating: 11kV · · Operating Temperate Range -50°C to +150°C · · Manufactured from electrolytic Copper tube with a purity greater than 99.9% · · Electrolytically tin-plated to avoid oxidisation
✓ In stock – Delivery in 1–2 days
Description
Technical Specifications Technical Specifications Copper tube crimping lug Material Copper Connecting angle 180° (horizontal) Surface protection Tinned Flange shape Ring shape Nominal cross section 16 mm² Bolt dimension (metric) 6 Number of fixing holes 1 Insulated No · Technical Data Sheet – Click to Download
