Newlec Enclosure Fan 230V AC 105/120mmCubed at 50/60Hz
Newlec Enclosure Fan 230V AC 105/120mmCubed at 50/60Hz
Newlec Enclosure Fan 230V AC 105/120mmCubed at 50/60Hz - Image 2

Newlec Enclosure Fan 230V AC 105/120mmCubed at 50/60Hz

£248.50 Incl. VAT

· · 105/120m³/h unimpeded throughput (50/60Hz) · · 93/108m³/h with 2 outlet filters (50/60Hz) · · 93/108m³/h with 2 outlet filters (50/60Hz) · · Fan colour: RAL 7035 · · Operating voltage 230 VAC 50/60Hz · · Tool Free Mounting · · IP54 Protection as standard · · Tool Free Spring terminal for quick wiring connection (all units except 3237) · · Tool Free change of fan direction. Just remove the fan unit and spin 180 degrees and click back in place · · Patented diagonal impeller blade design. This throws the air into the enclosure in numerous directions, rather than a traditional fan which just point in one direction. This improves cooling effectiveness and reduces hot spots

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: NLFAN105M Categories: , , , , , Brand: Product Code: 2500907735

Description

Technical Specifications  Technical Specifications Ventilator for enclosure Degree of protection (IP rating) IP54 Colour Grey Width 204 mm Voltage type AC Height 204 mm RAL number 7035 Depth 114 mm Operating voltage at AC 50 Hz 230 – 230 V Operating voltage at AC 60 Hz 230 V · Technical Data Sheet – Click to Download
