Ventcroft 6243Y NKT instal 1.0mm Grey 3-Core & Earth 100m PVC Basec
Ventcroft 6243Y NKT instal 1.0mm Grey 3-Core & Earth 100m PVC Basec
Ventcroft 6243Y NKT instal 1.0mm Grey 3-Core & Earth 100m PVC Basec - Image 2
Ventcroft 6243Y NKT instal 1.0mm Grey 3-Core & Earth 100m PVC Basec - Image 3
Ventcroft 6243Y NKT instal 1.0mm Grey 3-Core & Earth 100m PVC Basec - Image 4

Ventcroft 6243Y NKT instal 1.0mm Grey 3-Core & Earth 100m PVC Basec

Pack of 100

£88.44 Incl. VAT

· · Flat, Grey PVC sheath, PVC isulated cores with CPC fixed building cables · · BS 6004:2012 +A1 2020, BS EN 60228, BS EN 50575, CPR Class Eca · · BASEC certified,100% compliant and premium quality. · · All sizes supplied on user friendly, damage resistant sturdy Plastic or Plywood reels · · All Reels are weather resistant · · Plastic Reels are 100% made with recycled material and reusable by Ventcroft when returned · · Annealed Solid copper conductors · · Ideal for Power & Lighting circuits · · Ideal for fixed wiring in residential and commercial buildings · · Manufactured in EU, and wound in UK

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: VWY-310E10GRY Categories: , Brand: Product Code: 2501610238

Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Reaction-to-fire according to EN 13501-6: Smoke production None Protective barrier None Reaction-to-fire according to EN 13501-6: Flaming droplets/particles None Armouring/reinforcement None Sheath colour Grey Reaction-to-fire according to EN 13501-6: Acidity None Reaction-to-fire according to EN 13501-6: Class Eca Core colour Several Conductor material Copper Shape of conductor Round Sheath material Polyvinyl chloride (PVC) Conductor category Class 1 = solid Core insulation material Polyvinyl chloride (PVC) Conductor surface Bare Cable geometry Flat Core identification Colour Weight 89 kg/km Conductor resistance at 20 °C 18.1 Ohm/km Nominal voltage U0 300 V Nominal voltage U 500 V Nominal cross sectional area of conductor 1 mm² Max. conductor temperature 70 °C Min. permitted bending radius, stationary application/permanent installation 4 mm Number of cores 3 Permitted cable outer temperature during assembling/handling -5 °C Permitted cable outer temperature after assembling without vibration -40 °C Suitable as installation cable Yes Certified as airport lighting cable No Certified for shipboard application No Low temperature resistant according to EN 60811-504+505+506 No Core identification according to HD 308 S2 Yes Screen No Oil resistant according to IEC 60811-404 No Twisted cores No Drain wire No With protective conductor Yes · Technical Data Sheet – Click to Download
