Ventcroft 6242Y NKT instal 2.5mm Grey Cable 2-Core Twin & Earth 100m PVC Basec
Ventcroft 6242Y NKT instal 2.5mm Grey Cable 2-Core Twin & Earth 100m PVC Basec
Ventcroft 6242Y NKT instal 2.5mm Grey Cable 2-Core Twin & Earth 100m PVC Basec - Image 2
Ventcroft 6242Y NKT instal 2.5mm Grey Cable 2-Core Twin & Earth 100m PVC Basec - Image 3
Ventcroft 6242Y NKT instal 2.5mm Grey Cable 2-Core Twin & Earth 100m PVC Basec - Image 4

Ventcroft 6242Y NKT instal 2.5mm Grey Cable 2-Core Twin & Earth 100m PVC Basec

Pack of 100

£114.84 Incl. VAT

· · Flat, Grey PVC sheath, PVC isulated cores with CPC fixed building cables · · BS 6004:2012 +A1 2020, BS EN 60228, BS EN 50575, CPR Class Eca · · BASEC certified,100% compliant and premium quality. · · All sizes supplied on user friendly, damage resistant sturdy Plastic or Plywood reels · · All Reels are weather resistant · · Plastic Reels are 100% made with recycled material and reusable by Ventcroft when returned · · Annealed Solid copper conductors · · Ideal for Power & Lighting circuits · · Ideal for fixed wiring in residential and commercial buildings · · Manufactured in EU, and wound in UK

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: VWY-225E15GRY Categories: , Brand: Product Code: 2501610234

Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Sheath colour Grey Armouring/reinforcement None Reaction-to-fire according to EN 13501-6: Flaming droplets/particles None Reaction-to-fire according to EN 13501-6: Smoke production None Protective barrier None Reaction-to-fire according to EN 13501-6: Acidity None Core colour Several Reaction-to-fire according to EN 13501-6: Class Eca Shape of conductor Round Sheath material Polyvinyl chloride (PVC) Conductor category Class 1 = solid Conductor material Copper Conductor surface Bare Core insulation material Polyvinyl chloride (PVC) Cable geometry Flat Core identification Colour Nominal voltage U 500 V Nominal cross sectional area of conductor 2.5 mm² Weight 118 kg/km Max. conductor temperature 70 °C Number of cores 2 Conductor resistance at 20 °C 7.41 Ohm/km Nominal voltage U0 300 V Min. permitted bending radius, stationary application/permanent installation 4 mm Permitted cable outer temperature during assembling/handling -5 °C Permitted cable outer temperature after assembling without vibration -40 °C Drain wire No Screen No With protective conductor Yes Oil resistant according to IEC 60811-404 No Low temperature resistant according to EN 60811-504+505+506 No Core identification according to HD 308 S2 Yes Suitable as installation cable Yes Certified as airport lighting cable No Certified for shipboard application No Twisted cores No · Technical Data Sheet – Click to Download
