nVent Hoffman Fan Filter IP54 110M3/H 19W 230V 177 x 177mm RAL 7035
nVent Hoffman Fan Filter IP54 110M3/H 19W 230V 177 x 177mm RAL 7035
nVent Hoffman Fan Filter IP54 110M3/H 19W 230V 177 x 177mm RAL 7035 - Image 2
nVent Hoffman Fan Filter IP54 110M3/H 19W 230V 177 x 177mm RAL 7035 - Image 3
nVent Hoffman Fan Filter IP54 110M3/H 19W 230V 177 x 177mm RAL 7035 - Image 4

nVent Hoffman Fan Filter IP54 110M3/H 19W 230V 177 x 177mm RAL 7035

£201.78 Incl. VAT

Filter Fan Air flow 98 m3/h, 230V, 50/60HZ, IP54 · · · Locking type: Side-locking clamp (lower side) · · 1 Cable entry on side · · M25 Internal thread · · Limiting temperature -40 to 125°C · · IP65 degree of protection · · Unsuitable for ModuPlug®

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EF220R5 Categories: , , Brand: Part Number: 2500362888

Description

Technical Specifications  Technical Specifications Ventilator for enclosure Degree of protection (IP rating) IP54 Voltage type AC Mounting method Snap mounting Width 202 mm Height 202 mm RAL number 7.035 Number of fans 1 Noise emission – dB(A) Operating voltage at AC 60 Hz – V Suitable for wall built-in Yes EMC-version No Operating voltage at AC 50 Hz 230 – 230 V Operating voltage at DC – V Depth – mm Volume flow, freeblowing 82 m³/h Rated power 19 W With protective cover No Suitable for 19 inch rack mounting No Air circulator No Roof ventilator No With filter Yes Built as slide-in ventilator Yes · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
